Compatible with a variety of liquids and chemicals.
Precision engineering for optimal flow rate and pressure.
Superior strength ensures reliable performance in demanding applications.
High-quality aluminum body for maximum strength.
Smooth operation with minimal noise and vibration.
| Model | GWP10A | GWP10C | GWP15A | GWP15C | GWP15 | GWP20 | GWP30 | GWP40 | GWP60 | GWP80 |
| Gasoline Power (HP) |
1.5-2.5 |
1.5-2.5 |
2.0-3.0 |
2.5 |
2.5 |
6.5 | 6.5 |
9-13 |
15 | 23 |
| Inlet / Outlet (mm) |
25/25 |
25/25 |
40/40 |
40/40 |
40/40 |
50/50 |
80/80 | 100/100 | 150/150 | 200/200 |
| Max. Lift (m) | 22 | 22 | 21 | 30 | 21 | 30 | 28 | 25 | 20 | 15 |
| Max. Flow (m3/h) / (GPM) |
7/31 |
7/31 |
12/53 |
15/66 |
10/44 |
33/145 |
60/264 |
80/352 |
150/660 |
300/1320 |
| Max. Suction (m) | 7 | 7 | 7 | 7 | 7 | 7 | 7 | 7 | 7 | 7 |
| Tank Capacity (L) |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
3.6 |
3.6 |
6 | 6 | 25 |
| N.W. / G.W. (KG) |
8/10 |
8/10 |
13/15 |
13/15 |
22/24 |
22/24 |
22/25 |
43/45 |
65/78 |
87/104 |
| Model | DWP20 | DWP30 | DWP40 | DWP60 |
|
Diesel Power (HP) |
5 | 7 | 10 | 13 |
|
Inlet/Outlet (mm) |
50/50 |
80/80 | 100/100 | 150/150 |
|
Max. Lift (m) |
28 | 30 | 25 | 25 |
|
Max. Flow (m³/h)/(GPM) |
35/154 |
50/220 |
80/352 |
150/660 |
|
Max. Suction (m) |
7 | 7 | 7 | 7 |
|
Tank Capacity (L) |
3.6 | 3.6 | 6 | 6 |
|
N.W. / G.W. (KG) |
36/38 |
44/53 |
67/76 |
115/127 |
